Thermal Scanning Probe Lithography Day
October 7, 2026
Address
Avenida Complutense 30
Madrid, Spain
Place
Escuela Técnica Superior de Ingenieros de Telecomunicación (ETSIT, Universidad Politécnica de Madrid)
Room
Salón de Actos del edificio C
Instituto de Sistemas Optoelectrónicos y Microtecnología (ISOM) and Heidelberg Instruments invite you to join us for a half-day event exploring the latest developments in nanolithography.
The event will introduce thermal scanning probe lithography (t-SPL) and progressively delve deeper into the ongoing research at ISOM, as well as the latest advances in processing technologies.
The event will conclude with a visit to the lab, where you will have the opportunity to see the NanoFrazor in action through a live demonstration.
Coffee and snacks will be provided by ISOM. The event is free to attend.
Please register below to reserve your spot.
Program
October 7 · 9:00 AM – 1:00 PM (UTC+2)
| Time | Topic | Speaker |
|---|---|---|
| 09:00 AM | Reception, Coffee | |
| 09:30 AM | Welcome | |
| 09:40 AM | Expanding the lithography toolbox: An overview of t-SPL applications | Vasilis Theofylaktopoulos Heidelberg Instruments |
| 10:10 AM | Fabrication of nanodevices with the NanoFrazor at ISOM to explore energy storage and magnetic applications | Clara Moreno Bravo Manuel Abuín ISOM |
| 10:40 AM | Microfabrication tips and tricks with t-SPL | Andrea Ubezio Heidelberg Instruments |
| 11:10 AM | Coffee Break | |
| 11:30 AM | NanoFrazor Demo | |
| 01:00 PM | End of Program |
